Event Lighting CLAMPB160S Universal Marquee Beam Clamp – Silver
The Event Lighting CLAMPB160S is a versatile universal beam clamp designed for secure mounting on marquee beams, steel structures, and support frames. Engineered for professional event and installation use, this clamp is suitable for beam widths ranging from 40–130mm.
With a maximum load rating of 100kg, the CLAMPB160S provides a reliable mounting solution for lighting fixtures, signage, and lightweight production equipment. The clamp includes multiple threaded mounting options featuring 2× M10, 2× M12, and 1× M14 holes, allowing flexible fixture attachment.
Weighing 1.3kg and finished in silver, this heavy-duty beam clamp is ideal for outdoor events, temporary structures, and marquee installations where secure rigging is required.
Specifications
- Beam fit range: 40–130mm
- Maximum load: 100kg
- Threaded holes: 2× M10, 2× M12, 1× M14
- Weight: 1.3kg
- Colour: Silver
Features
- Universal marquee and beam mounting clamp
- Multiple threaded mounting options
- Heavy-duty construction for professional use
- Suitable for temporary and event structures
- Designed for lighting and production equipment
Ideal for
- Outdoor events and marquees
- Live event and festival setups
- Lighting and signage mounting
- Temporary structure installations
