Event Lighting CLAMPB160 Universal Marquee Beam Clamp
The Event Lighting CLAMPB160 is a professional universal beam clamp designed for secure mounting on marquee beams, steel frames, and structural supports. Suitable for beam widths ranging from 40–130mm, this clamp provides a versatile rigging solution for event and installation applications.
With a maximum load rating of 100kg, the CLAMPB160 is suitable for mounting lighting fixtures, signage, and other lightweight production equipment. The clamp includes multiple threaded mounting points, featuring 2× M10, 2× M12, and 1× M14 holes, allowing flexible fixture attachment options.
Constructed for durability and reliability in temporary structure installations, this beam clamp is ideal for outdoor events, marquees, and production setups where secure mounting is required.
Specifications
- Beam fit range: 40–130mm
- Maximum load capacity: 100kg
- Threaded holes: 2× M10, 2× M12, 1× M14
- Weight: 1.3kg
Features
- Universal marquee beam mounting clamp
- Multiple threaded attachment options
- Heavy-duty construction for professional use
- Suitable for temporary event structures
Ideal for
- Outdoor events and marquees
- Live event and festival setups
- Lighting and signage mounting
- Temporary production installations
